Coaxial cable RG59 Triple 75ohm

Group Coaxial Cable RG59 75Ohm
PriceUS $0.08 / meter
Min. Order 10000 meter
Terms of Payment L/C, D/P, T/T, Discuss
Update Time 2017-12-22
Item specifics
Place of OriginZhejiang,China(Mainland)
Brand NameWEIMAI
Conductor MaterialCCS/CCA/Solid Copper
Insulation MaterialPE
Braid Density40%-90%
1st shieldBonded Foil
2st shieldBraided Shield
JacketPVC
  • Description
  • Product review

Coaxial Cable China Manufacturer Supplier

Coaxial Cable RG59 Triple 75ohm

Impedance:50±3Ohm                                                             Capacitance:16.0±3pf/ft(Nom.)     Velocity of Propagain:84%                                                    FOB Pront :ShangHai/NingBo


Specifications
Center Conductor
0.81+0.005mmSolid Copper
Dielectric
3.66+0.052mm Fomd PE
Braid Coverage
95%Copper
Jacket
6.1+0.010mm PVC
Jacket Thickness
0.0381mm
Center Conductor
2-18 AVG Stranded Copper (7X0.38mm)
Dielectric
Solid PE 1.85mm
Jacket
3.81mm
Characteristics
Sparker Test:
2000AVC
Dielectric Strength
Conductor to shield:2000DVC
Impedance:
75±3OHM
Capacitance
16.0±3pf/ft(Nom).
Velocity of propagation
84%
DCR:
10.5ohms/1000ft.(nom.)Coax
