RG6 WITH MESSENGER
Review
Description
Coaxial Cable China Manufacturer Supplier Made in China
RG6 WITH MESSENGER
Impedance:75±3Ohm Capacitance:54±3pF/m
Velocity of Propagain:82% FOB Pront :ShangHai/NingBo
| 1) Construction |
|---|
| Center Conductor: | 1.02+0.01mm Solid Copper/Copper Clad Steel |
|---|---|
| Dielectric: | 4.57+0.05mmFoam PE |
| Shield: | Bonded Al Foil |
| Braid Coverage: | 60%Al |
| Jacket: | 6.90+0.10mmPVC |
| Messenger: | 1.15+0.05mmCCS (1.30 Steel) |
| Jelly/APD | Per Customers Special Requirement |
| 2) Characteristics |
|---|
| Sparker Test: | 4000VAC |
|---|---|
| Impedance: | 75+3 Ohm |
| Capacitance: | 54+3pF/m |
| Velocity of Propagation: | 82% (min) |
| Return Loss: | 20dB min (5-2300MHz) |
| 3) Attenuation |
|---|
| Attenuation | [@68o F. (20o C.)] |
|---|
| Frequency (MHz) | Maximum (dB/100 ft.) | Maximum (dB/100 m) |
|---|---|---|
| 5 | 0.58 | 1.9 |
| 50 | 1.5 | 4.9 |
| 100 | 2.0 | 6.5 |
| 200 | 2.8 | 9.2 |
| 400 | 4.1 | 13.6 |
| 700 | 5.6 | 18.4 |
| 900 | 6.2 | 20.3 |
| 1000 | 6.5 | 21.4 |
| 1450 | 8.0 | 26.2 |
| 1800 | 8.5 | 27.9 |
| 2100 | 9.5 | 31.1 |
| 2250 | 10.0 | 34.0 |
| 3000 | 11.4 | 37.5 |
